I've written about how the Raspberry Pi 4 needs a fan, and more recently how it might not.īut I realized, I've done a lot of testing for my own needs, but never compiled them into one concise post. The 3 model B+ was the first generation that had me concerned more about cooling (the CPU gets hot!), and the Pi 4's slightly increased performance made that problem even more apparent, as most of my heavier projects resulted in CPU throttling. I've used every model through the years, and am currently using a mix of A+, 2 model B, and 4 model B Pis.

HOWTO: Building and Installing the Raspberry Pi 3 “Touch” Audio Streamer.From home temperature monitoring to a Kubernetes cluster hosting a live Drupal website, I have a lot of experience running Raspberry Pis.

When looking for a remote to use with a Flirc, make sure it has play and pause buttons.

I run LMS on a dedicated RPi4B with attached SSD.

#Flirc raspberry pi case uk pro

In the summer here in the UK the Touch Pro machine will definitely need the fan.

A RPi4B is overkill for a pure player and runs hotter than a RPi3.

#Flirc raspberry pi case uk download

It is very easy to set up the WiFi just after you download piCorePlayer to the SD card. Notice that the Pi is held in place by a piece of plastic that came with the SmartiPi. The Flirc V2 USB receiver does not show from the front making for a very good solution.ĭAC+ card with right-angle phono adapters picked up from eBay. It is shorter and hides really well behind this case. It uses a RPi3A+ which is a very overlooked option. This one is a Touch 1 case I happened to pick up second hand. SmartiPi Touch 1 with RPi3A+ and HiFiBerry DAC+ # My understanding is that a RPi4B is much better for a USB DAC than any other. This player is in my office and I don’t mind that it doesn’t look so good because the sound is amazing. SmartiPi Touch 2 with RPi4B and USB DAC # Since these photos were taken I have run a USB extension cable out of the bottom with the Flirc V2 receiver hidden in the hifi cabinet out of sight. Look carefully and you will notice that I have mounted the RPi deep inside the machine away from the sides.

#Flirc raspberry pi case uk upgrade

I don’t mind because I upgrade the software in place

Once any of these machines are built the SD card is hard to access.

My advice - buy an official power supply with switch built in This combination resulted in a voltage drop enough to give me continuous warnings.

I added a switch to the power cable and then added a right-angle adapter.

You can easily use a RPi3A+ if you just want wifi.

SmartiPi supply an optional metal plate for the bottom to counter balance the screen.

I cut holes in the back of the case using a cheap, Dremel-style, tool.

The standard size back of the case is all you need for a standard HAT.

Since the photos were taken I have added the fan You will have to dismantle the whole thing to put them in afterwards.

#Flirc raspberry pi case uk install

Install the power cables for the fan to the screen (step 1 of the SmartiPi instructions) even if you do not intend to use them immediately.

Here are the lessons I learned from this one:

USB2 Extension cable to run Flirc outside.

Justboom DigiHat - I run digital output on this player.

Add-on switch to that power supply so I can turn it off easily (see notes below).

The layout allows for everything to be hidden and adapted to any combination of hardware. It is easily the best looking and most suitable case to make a great looking player. This player uses the latest model, the Touch Pro. SmartiPi Touch Pro with RPi3B+ and Justboom DigiHat # My goal is simple, to build a player that I do not have to apologise for. There are 3 different players shown here and the various options and tradeoffs are discussed along with shopping lists. This page shows various recipes for using the official touchscreen and SmartiPi cases from SmartiCase to make a really great looking player.
